Scissor lift
Mini self-propelled scissor lift for cleaning
- Description: Mini self-propelled scissor lift for cleaning
Mini self-propelled scissor lift for cleaning
Model | PNC0307 | PNC0407 |
Max working height | 3m | 4m |
Loading capacity | 240kg | 240kg |
Occupants | 1 | 1 |
Overall length | 1.32m | 1.32m |
Overall width | 0.76m | 0.76m |
Overall height | 1.83m | 1.92m |
Platform dimension | 1.15*0.6m | 1.15*0.6m |
Platform extension | 0.55m | 0.55m |
Extension load | 100kg | 100kg |
Wheel base | 1m | 1m |
Turning radius | 0m | 0m |
Travel speed(Stowed) | 4km/h | 4km/h |
Travel speed(Raised) | 0.5km/h | 0.5km/h |
Up/down speed | 31/22 sec | 34/25sec |
Gradeability | 25％ | 25％ |
Drive tyres | Θ0.23*0.08m | Θ0.23*0.08m |
Drive motors | 2*24VDC/0.4kw | 2*24VDC/0.4kw |
Lifting motors | 24VDC/1.3kw | 24VDC/1.3kw |
Battery | 2*12V/100Ah | 2*12V/100Ah |
Charger | 24V/15A | 24V/15A |
Weight | 630kg | 660kg |
For any inquiries, contact us by Email or WP, please.
